Mitsubishi 24,000 BTU multi-zone hyper heat outdoor heat pump (MXZ-3D24NLHZ). This is an extremely efficient unit that can connect to a variety of indoor unit types and can handle three zones (indoor units). This system uses the new R454B refrigerant, and is the direct replacement for MXZ-3C24NAHZ*.

Unit Type 2-Ton Inverter Condenser Heat Pump
Product Line M-Series Hyper Heat
Operating Mode Cooling & Heating
Low Ambient Heat: YES
Number of Zones 3
Unit Capacity 24,000 BTU
Refrigerant Type: 454B

Outdoor Unit: MXZ-3D24NLHZ

(Non-Ducted // Mixed // Ducted)
Cooling at 95F: Maximum Capacity Btu/h 23,600 // 23,600 // 23,600
Cooling at 95F: Rated Capacity Btu/h 22,000 // 22,800 // 23,600
Cooling at 95F: Minimum Capacity Btu/h 11,600 // 11,600 // 11,600
Heating at 47F: Maximum Capacity Btu/h 30,600 // 30,600 // 30,600
Heating at 47F: Rated Capacity Btu/h 25,000 // 24,800 // 24,600
Heating at 47F: Minimum Capacity Btu/h 12,800 // 12,800 // 12,800
Heating at 17F: Maximum Capacity Btu/h 25,000 // 24,800 // 24,600
Heating at 17F: Rated Capacity Btu/h 15,400 // 15,400 // 15,400
Heating at 17F: Maximum Power Input W 3,627 // 3,711 // 3,795
Heating at -13F: Maximum Capacity Btu/h 20,400 // 20,200 // 20,000
SEER2: 20 // 17.20 // 14.40
EER2: 13 // 11.50 // 10
HSPF2: 10 // 9 // 8
Heating Minimum Temp -22 F
Cooling Minimum Temp 10 F

• Thermal Differential 1°F
• Seacoast protection: Seacoast protection
• Quiet operation: Outdoor units are whisper quiet.
• INVERTER-driven compressor
• Hyper-Heating INVERTER®: offers 100%
heating capacity at 5°F and 75% heating capacity at -13°F
• High pressure protection
• Compatible with M- and P-Series
• Built-in base pan heater
