Mitsubishi SLZ‑AF18NL with SLP‑18FAU grille and SUZ‑AA18NL condenser offers 18k BTU efficient heating/cooling for 750 sq ft. Features ultra-quiet operation, Wi-Fi compatibility, 4-way airflow, and durable Blue Fin coating for reliable, year-round comfort.

Unit Type: Multi Zone
Product Line: M-Series AF
Operating Mode: Cooling & Heating
Number of Zones: Multiple
System Capacity: 18,000 BTU
Line Set Size: 1/4" x 1/2"
WiFi Enabled: Yes with Comfort App
WiFi Built In: Yes

Indoor Unit SLZ-AF18NL
Standard Grille SLP-18FAU
Outdoor Unit SUZ-AA18NL
Remote Controller NOT INCLUDED

Cooling Capacity up to 18,000 BTU
Heating Capacity up to 21,800 BTU
SEER2 17.5
EER2 12
HSPF2 9.6
Heating Minimum Temp -14 F
Cooling Minimum Temp -1 F
Room Cooling/Heating Capacity up to 750 sq ft

INDOOR UNIT FEATURES
• Built-in drain condensate lift mechanism (lifts to 33”)
• Ceiling-recessed cassette : Ceiling-recessed cassette (24”x24”)
• Fresh air intake: Fresh air intake provided in the main body
• Individual vane control
• Install Konnect Series: Install Konnect Series in a drywalled ceiling (with an access panel for servicing) or in a 2’x2’ drop ceiling
• Light commercial: Units with this icon are suitable for light commercial applications such as small offices, restaurants, and retail.
• Long-life air filter included
• Multi-zone: A multi-zone unit provides the temperature management of multiple zones within a building.
• Multiple control options, including the comfort app for remote access, third-party interfaces, and both wired and wireless controllers
• Optional 3D i-see Sensor®: The advanced sensor scans each room to produce a complete thermal profile that includes heat signatures based upon size,
temperature and movement, then adjusts temperature and airflow based on user preference, and saves energy according to room occupancy.
• Powerful Mode: Temporarily drops or raises the set point and fan speed in order to quickly bring the room to the desired temperature.
• Up and down swing-mode: An indoor unit with this capability can move air up and down throughout the room like an oscillating fan using the horizontal
vanes.
• Wide airflow pattern: Wide airflow pattern for excellent air distribution
OUTDOOR UNIT FEATURES
• Blue Fin Coating: An anti-corrosion treatment applied to the aluminum fins of the heat exchanger of the outdoor unit to protect against corrosion caused
by salt, sulfur, and other airborne contaminants, especially in coastal and industrial areas.
• High-performance grooved piping : High-performance grooved piping for increased heat exchange efficiency
• Hot-Start Technology: Hot-Start Technology ensures the fan only activates once the heat exchanger is warm, preventing cold air blasts during start-up.
• INVERTER-driven compressor: An inverter-driven compressor generates the precise capacity needed to maintain a temperature set point.
• Joint Lap DC Motor: Innovative Joint Lap DC Motor leads to high efficiency and reliability
• Outdoor unit directed power: The outdoor unit powers the indoor unit, and should a power outage occur, the system is automatically restarted when
power returns
• Pulse Amplitude Modulation technology: Pulse Amplitude Modulation technology enhances energy efficiency by adjusting the power supply to optimize
compressor performance, ensuring precise capacity control and reduced energy consumption.
• Quiet operation: Quiet operation units are as quiet as a typical conversation, and most indoor units are whisper quiet.
• Single-zone: One outdoor unit connects to one indoor unit to control the comfort in a single space.

Airflow Cooling CFM, Dry: 300–420–475
Airflow Heating CFM, Dry: 300–420–475
Noise Level dB(A), Heating: 32–40–43
Unit Size W x D x H: 22-7/16" x 22-7/16" x 8-3/16"
Grille Size W x D x H: 24-19/32" x 24-19/32" x 13/32"
Weight: 31 lbs
