The Mitsubishi PEAD‑AA09NL & SUZ‑AA09NL is a 9,000 BTU ducted heat pump system ideal for spaces up to 350 sq ft. Featuring quiet 23 dB(A) operation, slim 9-7/8″ design, R-454B refrigerant, and smart kumo cloud® controls with ENERGY STAR® efficiency.

Unit Type: Single Zone
Product Line: M-Series PEAD
Operating Mode: Cooling & Heating
Number of Zones: 1
System Capacity: 9,000 BTU
Line Set Size: 1/4" x 3/8"
WiFi Enabled: Yes with Comfort App
WiFi Built In: Yes

Indoor Unit PEAD-AA09NL
Outdoor Unit SUZ-AA09NL

Cooling Capacity up to 9,000 BTU
Heating Capacity up to 13,000 BTU
SEER2 18.8
EER2 13.2
HSPF2 11.5
Heating Minimum Temp -1 F
Cooling Minimum Temp -14 F
Room Cooling/Heating Capacity up to 350 sq ft

Airflow Cooling CFM, Dry: 265-283-318-353
Airflow Heating CFM, Dry: 265-283-318-353
Noise Level dB(A), Cooling: 25-26-28-31
Noise Level dB(A), Heating: 25-26-28-31
Size W x D x H: 35-7/16" x 28-7/8" x 9-7/8"
Weight: 58 lbs
